Specifications:

• Number of Power Amps 5
• Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive):  75 W
• Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive):  100 W
• Power Output (6 ohm, 1 kHz, 1% 1ch Drive):  135 W

General:

• Speaker impedance: 4-16Ω/ohms
• Input sensitivity: 200 mV
• Frequency response: 10 Hz – 100 kHz — 1, –3 dB (Direct Mode)
• S/N Ratio: 98dB (IHF-A-weighted, Direct Mode)
• FM section (Tuning frequency range): 87.5 – 107.9 MHz
• AM section (Tuning frequency range): 520 – 1710 kHz
• Power Supply: AC 230 V, 50 Hz
• Power Consumption in W: 340
• Power Consumption No-Sound (ECO On / Off) in W: 29 W / 39 W
• Weight in kg: 7.8
• 3.5mm audio line-in connection: Yes
• System Remote Control: RC-1243
• Standby Consumption in W: 0.1
• CEC Standby Consumption in W: 0.5
• Network Control On Consumption in W: 2.0
• Available colours: Black / Premium Silver: Yes / No
• Maximum Dimensions: w/ Antenna 43 x 33 x 21 mm
• w/o Antenna: 43× 33× 15cm
• Carton Maximum Dimensions (W x D x H) 52 x 43 x 23 mm
• Carton Weight (inc. product) in kg: 9.7

Inputs Outputs:

• HDMI In / Out: 6 / 1
• Composite In / Out: 2 / 1
• Phono (MM) In: Yes
• Analogue In/out: 2 / –
• Digital Optical In/Out: 2 / No
• Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes
• Pre-out / Main-in: 0.2 ch / no
• Headphone output: Yes
• Ethernet: Yes
• AM/FM Tuner: Yes
• Digital In: Optical / Coaxial: 2 / 0
• Multichannel Preout: o (0.2)
• Subwoofer Out: 2
• Number of Speaker Terminals: 5
• USB Audio / Made for iPod / Made for iPhone: o / AirPlay / AirPlay
• Speaker Terminal: Gold Plated Screw / Regular Screw: No / Yes
• FM Tuner with RDS: Yes

Multichannel Surround:

• DTS Neo:X / DTS Neural:X: NEO: 6 / –
• Max Number of Processing (Preamp) Channels: 5.1
• DTS HD Master / DTS:X: Yes / No
• Dolby TrueHD / Dolby Atmos: Yes / No
• Multichannel Stereo: Yes
• Dialogue Enhancer: Yes
• Dolby ProLogic II / Dolby Surround: Yes / No

Sound Enhancements:

• Discrete Power Amplifier: 5
• Audyssey: MultEQ
• Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
• Compressed Audio Restorer: Yes

Network:

• DSD Audio Streaming: up to DSD5.6
• Gapless playback: Yes (FLAC, WAV, ALAC, DSD)
• Internet Radio: TuneIn
• Compatible with Remote APP for Smart Phones: Android / iOS
• Compatible with Remote APP for Tablets: Android / iOS / Amazon Kindle
• HEOS Multiroom and Streaming: Yes
• Lossy Formats: MP3 / WMA / AAC: Yes / Yes / Yes
• Lossless Formats: FLAC / ALAC / WAV: Yes / Yes / Yes
• FLAC HD 192/24: Yes
• WAV 192/24: Yes
• ALAC 192/24: Yes
• AirPlay 2: Yes
• Roon Tested: Yes
• Spotify Connect / Tidal / Deezer / others : Yes / Yes / Yes / Yes
• Amazon Prime Music / Pandora: Yes / No
• Ethernet Ports: Yes
• Wi-Fi: Yes
• Bluetooth: Yes
• Bluetooth Re-transmit for Bluetooth headphones: Yes

HDMI:

• HDMI Inputs: Back / Front: 6 (3x 8K) / 0
• HDMI max Resolution (8k / 4k): 8k/60 – 4k/120
• HDMI to HDMI Scaling: up to 8K 60/50
• HDCP2.3 support: Yes
• HDMI: 8K / 4K / CEC / eARC: Yes / Yes / Yes / Yes
• HDMI: Dolby Vision / HDR 10 / Dynamic HDR / HLG: Yes / Yes / Yes / Yes

Others:

• Auto Speaker Setup by Microphone:  Audyssey MultEQ
• FL Display: 1 line
• Graphic User Interface – GUI: Hybrid GUI
• GUI Languages: 9
• Voice Control – Works with Amazon Alexa: Yes
• Voice Control – Google Assist / Apple Siri: Yes / Yes
• Setup Assistant: Yes
• Quick Select Plus / Quick Select: Yes / No
• Firmware Update by: Network / USB: Yes / Yes
• Variable Cross Over: Yes
• Optimized Bass Redirection: Yes
• ECO Mode: Yes
• Auto Power Off: Yes
• Sleep Timer: Yes

Multi-room CI:

• HEOS Multiroom integrated: Yes
• TV Sound grouping: Yes
• Main room multichannel audio – Zone stereo downmix: Yes
• Webbrowser Setup: Yes
• IP Control / RS232 Control / Web Control / App Control: Yes / No / Yes / Yes
